Impedance 4 Ohms
Frequency Response 30-22000 Hz
Sensitivity 91 dB
Recommended Amplifiers Drive Units 40 - 250 Watts
2 x 6” Woofer (3) XPP "Spidercone“
6” Midrange X3P Cone
1.1” Dome-Tweeter Hand-Coated VA Silk Dome
Bass System Bass Reflex
Bass Function Impulse Optimizing QB 3 (Quasi-Butterworth)
Crossover Components MKP Capacitors, 1% tolerance Coils 0,7% tolerance, Midrange/Tweeter Section Air Coils, Special Powder Core for Bass Section Metal Film Resistors 1% tol., Inductance Free
Crossover Function 3-way, 6 dB and 12 dB Bessel
Weight per Pair 130 Ibs
Dimension (W x H x D) inches 6.7 x 38.9 x 12.9“ (without spike assembly) 8.5 x 40 x 14.75 (with spike assembly)
Dimension (W x H x D) mm 170 x 987 x 328 mm (without spike assembly)
