Power Output: 2 channels at 200W into 8Ω, or 1 channels at >650W into 8Ω(bridge mode), ~1000W into 4Ω
Distortion: Less than 0.01% input to output
Signal/Noise: Better than –100dB
Inputs: Balanced on XLR-3F connectors and unbalanced on phono
Outputs: 2 output sets per channel, terminal posts
Construction: Dual-mono construction. Four pairs of output devices and four audiophile-grade PSU smoothing capacitors per channel. Ultra low impedance error-corrected output stage. DC coupled, with no capacitors in the signal path. Soft start and thermal management in main assembly. Optimised magnetic design based on
DSP8000. Meridian black or silver finish in metal & glass
Dimensions: Width: 440mm (17.32in); Depth: 350mm (13.78in) plus connectors; Height: 132mm (5.20in)
Rack Mounting: Kit available from Meridian authorized dealers
Weight: 20 kg (44 lbs)
Controls: Rear-panel power switch; per-channel switches for balanced or single-ended input; Bridge/Stereo mode switches on channels 1 and 5
Trigger: Wide voltage-range (5–30V, AC/DC) trigger input for remote standby/on switching
Display: Power/Fault indicator and per-channel operation LEDs
Power: Versions: 100, 110, 115, 220, 230, 240 Vac, 50/60Hz. Standby 17VA, Idle 48VA, Both channels driven 600VA
