Frequency Response :
20Hz – 20kHz, +0.0 / -0.2dB.
0.25 – 250kHz, +0 / -3dB.
Input impedance : 10K
Av Input impedance: 47K
THD+N : 1kHz < 0.05%, 20kHz <
0.25%.
Signal to Noise
< -100dB “A-weighted”
Gain : 38dB.
Input sensivity : 350mV.
Input sensivity AV-input : 1V.
Output Power :
Both channels driven
2 x 100Watt in 8 Ohm.
2 x 200Watt in 4 Ohm.
2 x 350Watt in 2 Ohm.
Output voltage :
RMS : 28.3V
Peak to Peak : 80 V
Output impedance : 0.038 Ohm
Power consumption :
Idle : 130Watt.
Max : 800Watt.
Dimensions:
H. 145 mm W. 480 mm.
D. 420 mm.
Weight
Shipping weight 21 kgs.
Unit only 18 kgs
