AUDIO
Main Channel Amp In Balanced: 1, Unbalanced: 1
Bridge Mono Mode Yes
Headphone Out 0
Analog L&R In 0
Analog L&R Out 0
OTHER
External control (RS232C) RS-232C: 0, Trigger In: 1
D-Bus Remote (RC-5) In/Out 0/0

Number of Channels 2
Output Power/Channel (20Hz - 20kHz) Stereo Mode: 110W x2 (8 ohms), 220W x2 (4 ohms), BTL Mode: 420W (8 ohms)
HDAM HDAM-SA3
Power Transformer Very Large Capacity Toroidal w/Shielded Case
Discrete Amplifier Stage Current Feedback Amplifier Stage
Individual Level Adjust Balanced / Unbalanced Individual Gain Setting (-6dB/0dB/+6dB)
THD (20Hz - 20kHz) 0.02% (8 ohms)
Input Sensitivity/Impeance Balanced: 2V/22k ohms, Unbalanced: 2V/22k ohms
Frequency response 5Hz - 120kHz (1W, 8 ohms)
S/N Ratio Balanced: 101dB, Unbalanced: 101dB (IHF-A network, 1W, 8O)

Color Gold
Front Panel 3 pces Aluminum
Remote Control -
Power Requirement AC 120V 60Hz
Power Consumption 380W (UL60065)
Dimensions W x H x D (Inchs) 17-5/16" x 6-5/8" x 16-15/16"
Weight (lbs) 58.6
