Configuration Fully balanced, Dual-mono
Transport Mechanism Proprietary Design

Front Panel Controls Standby · Program · Display · Repeat · Input ·
Random · Time · Open/Close · Play · Pause ·
Scan/Skip Forward · Scan/Skip Backward · Stop
Front Panel Display Track number ·
Time - elapsed or remaining (track / disc)
Front Panel LED Indicators Program · Repeat - current track ·
Repeat - entire disc · Random

DAC / Digital Filter ESS ES9016 Sabre32 32-bit Hyperstream™
Frequency Response (audible) 20Hz - 20kHz +0/-0.1dB (CD transport)
Frequency Response (full range) 2Hz - 100kHz +0/-3dB (external source)
THD @ 1kHz, 0dBFS (A-weighted) < 0.001 %
IMD < 0.001 %
Dynamic Range > 120dB
Signal-to-noise ratio > 120dB @ full output
Slew Rate 50V/µs
Channel Separation > 116dB
Low Level Linearity < ±0.25dB at -90dBFS
Intrinsic Jitter < 1 picosecond RMS
Analog Outputs - Balanced 1 pair XLR
Analog Output - Single-ended 1 pair RCA
Digital Inputs (4) AES/EBU (XLR), S/PDIF (RCA), TosLink, USB Type-B
Bit-depth range - All inputs 16 - 24 bits
Sampling Frequency Rate range - All inputs 44.1 - 192kHz
Digital Outputs (2) S/PDIF (RCA) and AES/EBU (XLR)
Max. Analog Output @ 0dBFS - XLR 2.0 Volts
Max. Analog Output @ 0dBFS - RCA 2.0 Volts
Analog Output Impedance 100Ω
Digital Output Impedance S/PDIF 75Ω @ 0.5p-p
Digital Output Impedance AES/EBU 110Ω @ 3.7Vp-p

SimLink™ Port 1 input + 1 output each on 1/8" mini-jack
RS-232 Port 9-pin female DB connector
IR input 1/8" mini-jack

Remote Control FRM-3 All-Aluminum Full Function
Display Type 8 character dot matrix LED
Power Consumption @ idle 25 watts
AC Power Requirements 120V / 60Hz 220-240V / 50Hz
Fuse Replacement 120V / 220-240V 200mA short slow blow / 100mA short slow blow
Shipping weight 35 lbs / 16 Kgs
Dimensions (w x h x d) 18.75 x 4.1 x 16.81 in. (47.6 x 10.4 x 42.7 cm.)
