Mid-Woofer
Number 1
Basket Ø 7" (175 mm)
Voice coil Ø 1.5" (38 mm)
Cone material Carbon/Rohacell/Glass Fiber

Tweeter
Number 1
Type X-ART
Diaphragm area 4 inch² (2420 mm²)
Equiv. Diaphragm Ø 2" (56 mm)
Velocity transform ratio 4:1
Diaphragm weight 0.17 g
Built-in Amplifiers
Mid-Woofer 1
Type PWM
Amp. power RMS / music 100 W / 150 W
Tweeter 1
Type A/B
Amp. power RMS / music 50 W / 75 W

Control panel
Input Sensitivity -∞ to +14 dB
High Shelf EQ > 5 kHz ±6 dB
Low Shelf EQ < 300 Hz ±6 dB
Tweeter gain ±4 dB

Input connectors
Analog XLR / RCA

General data
Frequency response 42 Hz - 50 kHz
THD 90dB/1m > 100 Hz ≤0.5 %
Long term output ≥106 dB
Max. peak ≥114 dB
Crossover frequencies 2500 Hz
Input impedance 30 KOhm
Weight 20.3 lb (9,2 kg)
Magnetically shielded No
Height x Width x Depth 13.5" (337 mm) x 8" (201 mm) x 11" (280 mm)
Warranty 5 Years
Delivery contents Power cord, Manual
