Inputs:
4 x unbalanced high level inputs (RCA)
1 x unbalanced (RCA) as ”SURROUND-
BYPASS”
Signal difference left/right:
< 0,5 dB (from 0 dB to -40 dB)
Input resistance:
50 kΩ
Total transformer power:
330 VA (watts)
Power supply capacity:
> 50,000 μF
Rated power output:
2 x 120 watts on 4 Ω
(at THD+N = 0,1 %)
2 x 90 watts on 8 Ω
Rise time / fall time:
4.6 μs with 4 Ω load
Distortion (THD+N):
0.008 % on 4 Ω load with 1 kHz and 10 watts
0.005 % on 8 Ω load with 1 kHz and 10 watts
Signal-to-noise-ratio:
-89 dBA (ref. 6.325 V)
(A weighted)
Damping factor:
> 500
Dimensions (H x W x D):
96x482x400 mm/3.8x19.0x15.7 inches
Weight:
approx. 11 kg / 24.4 lbs.
