. Continuous Average Output Power (both channels driven, 20–20,000 Hz)
140 watts per channel into 4 ohms
1 120 watts per channel into 6 ohms
1 100 watts per channel into 8 ohms
. Total Harmonic Distortion (both channels driven, 20–20,000 Hz)
0.03% with 4 to 16-ohm load
. Intermodulation Distortion 0.01%
. Frequency Response HIGH LEVEL INPUT/POWER IN
20 – 20,000 Hz +0, –0.2 dB (for rated continuous average output)
3 – 150,000 Hz +0, –3.0 dB (for 1 watt output)
. Damping Factor 120 (with 8-ohm load, 50 Hz)
. Input Sensitivity, Input Impedance
. Output Voltage, Output Impedance
PRE OUTPUT: 1.13 V, 50 ohms
(at rated continuous average output)
. Gain HIGH LEVEL INPUT → PRE OUTPUT: 18 dB
POWER IN → OUTPUT: 28 dB
. Tone Controls Turnover frequency and adjustment range
BASS: 300 Hz ±10 dB (50 Hz)
TREBLE: 3 kHz ±10 dB (20 kHz)
. Loudness Compensation +6 dB (100 Hz)
. Attenuator –20 dB
. Signal-to-Noise Ratio (input-converted noise)
. Power Level Meters Logarithmic compression, peak reading meters
Output dB/% scale
. Load Impedance 4–16 ohms
. Stereo Headphones Suitable impedance: 8–100 ohms
. Power Requirements AC 120 V/230 V 50/60 Hz
(Voltage as indicated on rear panel)
. Power Consumption 49 watts idle
280 watts in accordance with IEC 60065
. Maximum Dimensions Width 465 mm (18-5/16”)
Height 171 mm (6-3/4”)
Depth 422 mm (16-5/8”)
. Mass 21.7 kg (47.6 lbs) net
26.0 kg (57.3 lbs) in shipping carton
. Supplied Remote Commander RC-200
Remote control principle: Infrared pulse
Power supply: 3 V DC (IEC R03 batteries × 2)
Maximum dimensions: 56 mm × 175 mm × 26 mm
Mass: 153 g (including batteries)
