Measuring conditions: 25°C, 230V supply voltage.
Dimensions...........................450 x 165 x 360 mm (W x H x D incl. feet)
Weight .............................13 kg
AC supply .........................230V 50/60Hz
Power consumption.................. 30 W maximum
Power consumption on standby (incl. Power Bric)...................6 W

DAC, CD
THD & Noise .......................... -92dB
THD & Noise (HDCD) ................... -98dB
Frequency response ................... 0Hz – 44,000 Hz (-3dB)
Dynamic range...........................120 dB
DAC .................................. 24-bit, 192 kHz

DAC, SACD
THD & Noise .............................. -101dB
Frequency response ......................... 0Hz – 44,000 Hz (-3dB)
Dynamic range.................................130 dB

Analog outputs
Unbalanced
Output voltage.................................2 V
Output impedance ..............................180 ohms
Balanced
Output voltage..................................4 V
Output impedance ...............................360 ohms
Digital outputs
Coaxial, SPDIF
Output voltage..................................0.5 V pp
Output impedance ...............................75 ohms
Balanced, AES/EBU
Output voltage.................................5 V pp
Output impedance ..............................110 ohms
