AUDIO INPUTS
Analogue Inputs 3 x RCA, 1 x DIN for Naim phono preamplifier, 3.5mm front panel jack
Input Sensitivity 275mV
Input Impedance 47kΩ
USB Inputs Front panel socket
UPnP Hi-Res UPnP playback up to 24bit/96kHz (WAV and FLAC)
Antenna Inputs DAB/FM, WiFi
Tuning Range DAB (Band lll and L Band), FM 87.5-108MHz
Other Inputs Ethernet and iPod

AUDIO OUTPUTS
Analogue Outputs Line output (L & R RCA), sub output (Mono 2 x RCA), preamp output (4-pin DIN)
Line Outputs Fixed (level) 275mV rms, 600Ω
Line Outputs Variable (level) 775mV rms
Output Impedance 22Ω maximum
Frequency Response 20Hz - 50 kHz
Phase Response Linear phase, absolute phase correct
Power Outputs Naim phono amplifier
Other Outputs Headphone, 3.5mm jack
Signal To Noise Ratio (S/N ratio) L & R, 4mm “banana” sockets

SPEAKER OUTPUTS
Power Output 50W/channel, 8Ω, 90W/channel, 4Ω
UPGRADES
Other External power amp

CONNECTIVITY
Infra Red RC5
Remote Input 3.5mm jack on rear (RC5)
RS232 DE9 female
FORMATS
CD Formats Red Book
Disc Compatibility CD, CD-R
Audio Formats Supported Internet radio (WMA, MP3 streams, MMS), Playlists (M3U, PLS), MP3, AAC (up to 320 kbps, CBR/VBR) Apple Lossless (from iPod), Windows Media-formatted content (up to 320 kbps), WAV, FLAC, Ogg Vorbis

POWER
Mains Supply 100V, 115V, 230V; 50 or 60Hz
PRODUCT CERTIFICATIONS & LICENSES
Certifications Apple (made for iPod), vTuner Premium
Licenses MP3, AAC, DAB

PHYSICAL
Dimensions 87 x 432 x 314mm (H x W x D)
OTHER
Notes User interface for iPhone and iTouch devices, downloadable from App Store
Languages English, German, Italian, French, Spanish, Chinese, Dutch

FINISH
Front Black powder coated
Case Black powder coated
