Output: Voltage, RMS 17V
Voltage, Peak-to-peak 48V
Power 36W (25W original version)
Current peak-to-peak 22.8A
Damping factor 142
Output devices per channel 2
Pre-out impedance 47 ohms

Line input: THD + N, 20Hz to 20 kHz <0.02%
Signal / noise ratio -94dB A-wtd.
Input sensitivity for full power 120mV
Input impedance 43K ohms
Overload margin 37dB
Channel separation >52dB
Frequency response 20Hz to 20kHz +0,-0.3dB

Phono input: Cartridge type MM
Phono input response RIAA/IEC combined, see graph
Signal/noise ratio -81dB A-wtd.
Input sensitivity 3.3mV
Input impedance 47K ohms
Overload margin 29dB

Connections: Line level inputs 4 pairs line level RCA connectors
1 pair phono (moving magnet) level RCA connectors
Line level outputs 1 pair RCA preamp line outputs (level controlled by volume)
1 pair RCA tape line outputs (fixed level)
Digital inputs: 1 USB 1.1 (32, 44, 48kHz sample rates) type B connection for computer/pda (new version only)
Speaker outputs: 1 pair 4mm banana plug/binding posts per channel

Power requirement:
100 / 115 / 230Volts AC 50 / 60Hz (factory pre-set), 130W maximum
Accessories: Mains lead 10 Amp IEC type 1 off
Remote control A1, universal 1 off
Batteries Size LR03 or
AAA, manganese
alkaline type
2 off
Dimensions: Unit only
440mm 17 ⅓ inches wide
77mm 3 inches high inc. feet
290mm 11 ½ inches deep inc. terminals
Unit in shipping carton
536mm 21 inches wide
200mm 7 ¾ inches high
385mm 15 ¼ inches deep
Weight:
7.15 kg 15 ¾ lbs Unboxed
10.5 kg 23 lbs In shipping carton,
with all accessories
