Nominal Input Voltage: 95-145
Maximum Continuous Load: 1000VA
Maximum Peak Load: 1200VA
Dynamic Power Delivery: 0.5 second > 3600VA
Voltage Regulation: +/- 0.5V
Output Distortion Input 220-240VAC: 1200VA Resistive Load <0.9%
Output Distortion 230V: 240VAC 1200VA Reactive Load <0.9%
Output Distortion Input 110-130VAC: 1200VA Resistive Load <0.5%
Output Distortion Input 110-130VAC: 12000VA Reactive Load <0.5%
Output Impedance: <0.015 Ohm
Noise Reduction (all zones): 100KHz-2MHz >80dB
Efficiency @ 1200VA: Resistive Load > 85% Reactive Load > 85%
Input Frequency: 45-56Hz
Under Voltage Limit:
Continuous = -10% of setting
15 Sec Duration = -15% of setting
Over Voltage Limit:
Continuous= 5% of setting
15 Sec Duration= 10% of setting
Protection Modes: L-N, L-G, N-G
Energy Dissipation: 2440J
Peak Current Surge: 144,000A
Max Surge: 6,000 Volts
Clamp Level: 330V
Telco Protection: 320 Joules 395 volts
Coax Insertion loss: <1dB
DC Trigger config: Tip Positive
DC Trigger Voltage: 5-15 volts DC
Dimensions: 17” W x 14” D x 4” H
Weight: 37 lbs
