Audio
Digital inputs/sampling frequency
USB(2.0) Type B x 1, USB(2.0) Type mini B x 1 / 32 to 96kHz
AES/EBU x 1 / 32 to 192kHz
COAXIAL x 1 / 32 to 192kHz
OPTICAL TOS x 2, Round mini x 1 / 32 to 96kHz
SUPERLINK(BNC) x 1, SUPERLINK(D-SUB) x 1 / 44.1kHz
Master clock input BNC x 1: 44.1kHz available for SUPERLINK only
DAC Chip ESS ES9008 x 1
Digital filter Switchable between FLAT and PULSE
Fixed analog output Balanced XLR (2-pin hot) x 1: 4Vrms
Unbalanced RCA x 1: 2Vrms
Variable analog output Balanced XLR (2-pin hot) x 1: Max. 4Vrms
Unbalanced RCA x 1: Max.2Vrms
Headphone output 6.3mm x 1
Frequency response 20Hz to 20kHz, ±0.1dB
S/N ratio 110dB
Channel balance 105dB, 1kHz/0dB
THD 0.004%, 1kHz/0dB

General
Power supply AC120V/230V, 50/60Hz specified on rear panel
Power consumption 17watts
Dimensions 435(W) x 340(D) x 109(H)mm (incl. legs, terminals and knobs)
Weight Approx. 9kg (net)
Accessories AC power cable, BNC cable x 4, Remote control hand set, Owner's manual
Color Silver
EAN Code 49 92287 14940 3
