Signal Connector Level Impedance
Single ended analogue RCA phono 2V rms 300 Ohms
Balanced analogue XLR male 4V rms 600 Ohms
SPDIF electrical BNC 0.5V pp 75 Ohms
SPDIF optical TOSLINK
AES/EBU electrical XLR male 1V pp 110 OHMS
Sync Link input RCA phono 0-10 Vdc 10k Ohms
Knekt remote in/out RCA phono 4mA na
Mains input IEC 90 - 130Vac 180 - 260Vac 20 Watts max
Dimensions: 80mm H x 320mm W x 325mm D (3.15 x 12.6 x 12.8 inches)
Weight: 4.1kg (9 lb)
