System Super Audio CD, CD, CD-R and CD-RW
Digital Audio Output *i.LINK (AUDIO) 6pin ×1
4pin ×1
XLR ×2
(Use 2 terminals for Dual AES output)
RCA coaxial ×1
Word Clock BNC ×1
(44.1/88.2/100/176.4 kHz)
General Power supply AC 120V 60Hz
AC 220V 60Hz
AC 230V 50Hz
Power consumption 16W
Dimensions
(W×H×D) 442×126×332 mm
(17-3/8×4-15/16×13-1/16 ")
Weight 14kg (30-7/8lbs)
- Design and specifications are subject to change without notice.
- This product is available in three different power supply variations shown in the chart above. Make sure that the voltage shown on the rear panel matches the AC line voltage in your area.
- The shape of the AC inlet and plug of the supplied power cord depends on the voltage rating and destination country.
