Gain, Balanced 12 dB Bal in, Bal output
Gain, single-ended 12dB unbal in, unbal output
Freq. Response -3 dB @ 2 Hz
-3 dB at @ 100 kHz
Distortion @ 1KHZ < .1 % THD, typ .003% @ 2v
Maximum Output 20 volts rms bal out
7 volts rms unbal out
Output Impedance 200 ohms unbalanced
750 ohms balanced
Input Impedance 10K ohm unbalanced 20K ohm balanced
CMRR typ. -80 dB, 20 - 20kHz
Crosstalk typ. -90 dB, 20 - 20kHz
Output Noise floor < -110 dBV, 20 - 20kHz
Extl amp turn on 12 volts DC 50 mA continuous
Power Consumption 35 watts
Dimensions 17” W x 3.5”H x 13 “D each
Shipping Weight 70 pounds in packing carton, 3 units
