Type Solid State
Configuration Single-ended / 2-channel
Power Supply Transformer 320VA
Power Supply Capacitance 20,000µF
Class of operation - Amplifier A/AB
Single Ended Inputs (RCA) 5 pairs
Mini-jack Input (1/8") 1
Input Sensitivity 370mV - 3.0V RMS
Input Impedance 11,000Ω
Preamplifier Output 1 pair
Output Device Types - Amplifier Bipolars - 2 per channel
Output Power @ 8Ω 50 Watts per channel
Output Power @ 4Ω 100 Watts per channel
Output Impedance 0.04Ω
Damping Factor > 200
Gain 37dB
Dynamic Headroom 3dB
Signal-to-noise Ratio 101dB @ full power
Maximum Output Voltage 22 Volts
Slew Rate 20V/µs
Maximum Current - Peak 15 amperes
Maximum Current - Continuous 9 amperes
Frequency Response 10Hz - 100kHz (+0/-3dB)
Crosstalk @ 1kHz -78dB
IMD < 0.05%
THD (20Hz - 20kHz @ 1 watt) < 0.015%
THD (20Hz - 20kHz @ 50 watts) < 0.02%

SimLink™ Port 1 input + 1 output each on 1/8" mini-jack
RS-232 Port 9-pin female DB connector
IR input 1/8" mini-jack

Remote Control CRM-2 Full Function
Power Consumption @ idle 11 Watts
AC Power Requirements 120V / 60Hz 220-240V / 50Hz
Fuse Replacement 120V / 220-240V 4.0A long fast blow / 2.0 long fast blow
Shipping weight 22 lbs / 10 kgs
Dimensions (W x H x D) 16.9 x 3.5 x 14.4 in. (42.9 x 8.9 x 36.6 cm.)
