Audio data

Number of channels: 2

Frequency response: 20 Hz - 20 kHz, ± 0.1 dB

Harmonic distortion: < 0.004% (20 Hz - 20 kHz)



Signal-to-noise ratio

Linear: 102 dB (20 Hz - 20 kHz)

A-weighted: 108 dB



Channel separation: >90dB (20Hz - 20 kHz)



Output level

Fixed Output: 2.5 V, Ri < 500Ω, short-circuit-proof

Variable Output: 0 - 2.5 V Ri <500Ω, short-circuit-proof

Digital Output: 500 mVpp, Ri = 75Ω, short-circuit-proof

Headphones Output: 500 mVpp, Ri = <50Ω, short-circuit-proof



Channel balance: <0.2dB

Phase linearity: by digital filtering (over sampling)



General CD Specifications

Scanning frequency: 44.1 kHz

Quantisation: 16 bit linear/channel

Recording rate: 4.3218 Mbit/sec

Digital/analog conversion: 16 bit, quad over sampling



Optical pickup: AIGaAs semiconductor laser

Wave length: 780 nm

Error correction system: CIRC (Cross Interleave Reed Solomon Code)

Preemphasis: 50 or 15 μs (automatic changeover)

CD rotational speed: 500 - 200RPMS



Scanning speed: 1.2 - 1.4m/s

Constant speed: quartz-accurate

Max. Playing time: 74 min

Start-up time from pause: <0.6s

Search time for any CD location: <3s



Power requirements: 220 VAC + 5/-10%, 50 - 60 Hz

Power consumption: max. 25 W; Standby: <6W

Dimensions: 480x118x332 mm

Weight: 9.5 kg
