Configuration Single-ended
Transport Mechanism Proprietary Design

Front Panel Controls Standby · Play · Pause · Stop · Scan/Skip Forward ·
Scan/Skip Backward · Open/Close ·
Front Panel Display Track number ·
Time - elapsed or remaining (track / disc)
Front Panel LED Indicators Program · Repeat - current track ·
Repeat - entire disc · Random

DAC / Digital Filter BurrBrown PCM1793
Frequency Response (audible) 20Hz - 20kHz +0/-0.2dB
Frequency Response (full range) 2Hz - 72kHz +0/-3dB
THD @ 1kHz, 0dBFS (A-weighted) < 0.002 %
IMD < 0.005 %
Dynamic Range > 110dB
Signal-to-noise ratio > 110dB @ full output
Slew Rate 50V/µs
Channel Separation > 106dB
Low Level Linearity < ±1.0dB at -120dBFS
Intrinsic Jitter < 300 picoseconds RMS
Single-ended Analog Outputs 1 pair RCA
Digital Output S/PDIF (RCA)
Max. Analog Output @ 0dBFS - RCA 2.0 Volts @ 100Ω
Digital Output Impedance S/PDIF 75Ω @ 0.5p-p

SimLink™ Port 1 input + 1 output each on 1/8" mini-jack
RS-232 Port 9-pin female DB connector
IR input 1/8" mini-jack

Remote Control CRM-2 Full Function
Power Consumption @ idle 15 watts
AC Power Requirements 120V / 60Hz 220-240V / 50Hz
Fuse Replacement 120V / 220-240V 200mA short slow blow / 100mA short slow blow
Shipping weight 14 lbs / 6.25 kgs
Dimensions (W x H x D) 16.9 x 3.5 x 13.1 in. (42.9 x 8.9 x 33.3 cm.)
