Audio Characteristics
Power ( 4 Ω ) ………………………………. 2 x 120 W
Output Impedance ……………………. 0.02 Ω / 1 kHz
Power Bandwidth (60 W / 4 Ω / -3dB)10 Hz - 100kHz
Input Sensitivity /Impedance :
CD, FM, DVD, AUX.………………280 mV / 47 kΩ
PHONO ……………………………..18 mV / 47 kΩ
Impedance / Gain Tape Output ………..600 Ω / -6dB
Distorsion THD ( 20 Hz / 20 kHz ) ………….< 0.02 %
Signal to Noise Ratio ………………………….> 90 dB
Power Supply
Power consumption …………………………….350 W
Fuse type
T 2.5A / 250V (Slow Blow)
T 5.0A / 130V (Slow Blow)
Dimensions : ( W x D x H mm) ……..430 x 300 x 70
Weight ……………………………………………8.0 kg
