Disc Capacity 1
Playback Formats SA-CD(Stereo), CD, CD-R/RW(CD-DA)
HDAM HDAM-SA2
Current Feedback Analog Stage Yes
Power Transformer Large Capacity Toroidal w/ Copper Shielded Case
Zero-Impedance Plate Yes
Double Layerd Bottom Plates Yes
Audio DAC NPC SM5866AS Monaural DAC x2
Display On/Off Yes
Selectable Filters Yes
SA-CD/CD Text X / -

Analog L&R Out Balanced: 1, Unbalanced: 1
Headphone Out -
Digital Out Coax: 1, Opt: 1
Digital In -
Other In/Out -
OTHER
External control External Clock Input (BNC): 1

Format 1-Bit DSD
Sampling Frequency 2.8224MHz
Dynamic Range 114dB (Filter 3)
Frequency response 2Hz - 50kHz (-3dB)
THD 0.0009% (Filter 3)
CD Audio
Format 16-Bit Linear PCM
Sampling Frequency 44.1kHz
Dynamic Range 100dB (Filter 1)
Frequency response 2Hz - 20kHz
THD 0.0020% (1kHz, Filter 1)

Color Gold
Front Panel 3pces Aluminum
Remote Control Aluminum Top with Marantz Amp. Basic Control Function
Power Requirement AC 120V 60Hz
Power Consumption 26W
Dimensions W x H x D (Inchs) 17-5/16" x 5" x 16-1/4"
Weight (lbs) 36.4
