AUDIO OUTPUTS
Analogue Outputs DIN, RCA
Line Outputs Fixed (level) 2.1V rms at 1kHz
Output Impedance 10Ω maximum
Minimum Load Impedance 10kΩ
Frequency Response 10Hz – 20kHz, +0.1/-0.5dB
thd+n <0.1%, 10Hz -18kHz at full level
Phase Response Linear phase, absolute phase correct
De-emphasis ±0.1dB referred to main response
Digital Outputs (type) S/PDIF, 75Ω BNC

UPGRADES
Power Supply XPS, 555PS
Other DAC

CONNECTIVITY
Infra Red RC5
Remote Input 3.5mm jack on rear (RC5)
RS232 Optional (DE9 female)

FORMATS
CD Formats Red Book
Disc Compatibility CD, CD-R

POWER
Mains Supply 100V, 115V, 230V; 50 or 60Hz

PHYSICAL
Dimensions 87 x 432 x 314mm (H x W x D)

FINISH
Front Brushed and black anodised
Case Black powder coated
