Nominal Impedance
8 ohms
Recommended Amplifiers
20 to 100 watts
Frequency Response
38Hz to 30kHz
Sensitivity
87.5 db linear for 1 watt at 1 metre
Cabinet
Heavy, inert construction damped with special material and featuring slim, rigid front baffle design to aid dispersion.
Bass/Midrange
New 5" (130mm) ProAc unit featuring glass fibre weave cone, raised spider assembly, EXCEL magnet system and unique acrylic damping phase plug.
Tweeter
ProAc 3/4 dome unit with honeycomb wound voice coil, special damping and ferrofluid-cooled coil assembly.
Crossover
Finest components on dedicated circuit board with multistrand oxygen-free copper cable throughout. Split for optional bi-wiring/bi-amping.
Dimensions
12" (305mm) high, 6 5/8" (168mm) wide, 10 1/4" (260mm) deep including grille thickness of 12mm
Weight
20lbs (9 Kgs)
Mode
Stand mounted
Grille
Acoustically transparent crimplene
Finish
Standard Finishes:
Black Ash, Mahogany, Cherry, Maple.
Premium Finishes:
Rosewood, Ebony.
