Type Solid State
Configuration Dual-Mono / Balanced
Power Supply Transformer 2 x 0.5kVA
Power Supply Capacitance 66,800µF
Class of operation - Amplifier A/AB
Single Ended Inputs (RCA) 5 pairs
Balanced Inputs (XLR) 1 pair
Input Sensitivity 490mV - 6.0V RMS
Input Impedance 23,700Ω
Monitor Loop 1
Preamplifier Output 1 pair @ 50Ω (RCA)
Output Device Types - Amplifier Proprietary MOON BiPolars - 6 per channel
Output Binding Posts Gold-plated WBT
Output Power @ 8Ω 150 Watts per channel
Output Power @ 4Ω 250 Watts per channel
Output Impedance 0.02Ω
Damping Factor > 400
Volume Steps 1.0 dB from 0-30 and 0.5dB from 30-80
Gain Control M-eVOL (R-2R)
Gain 37dB
Signal-to-noise Ratio - Preamplifier 114dB (20Hz-20kHz)
Signal-to-noise Ratio - Amplifier 100dB @ full power
Maximum Output Voltage 45 Volts
Slew Rate 35V/µs
Maximum Current - Peak 40 amperes
Maximum Current - Continuous 20 amperes
Frequency Response 10Hz - 100kHz (+0/-3dB)
Crosstalk @ 1kHz -100dB
IMD unmeasurable
THD (20Hz - 20kHz @ 1 watt) < 0.02%
THD (20Hz - 20kHz @ 175 watts) < 0.05%
12 Volt Trigger Output Operation Direct Logic (0V = off, 12V=on) using a 3.5mm
mono jack with an output impedance of 1000Ω
and current requirement of 12mA
SimLink™ Port 1 input + 1 output each on 1/8" mini-jack
RS-232 Port 9-pin female DB connector
IR input 1/8" mini-jack
Remote Control FRM-2 All-Aluminum Full Function
Display Type 8 character dot matrix LED
Power Consumption @ idle 50 Watts
AC Power Requirements 120V / 60Hz 220-240V / 50Hz
Fuse Replacement 120V / 220-240V 6.0A long fast blow / 3.0 long fast blow
Shipping weight 58 lbs / 26 kgs
Dimensions (w x h x d) 18.8 x 5.4 x 18.1 in. (47.7 x 13.7 x 46.0 cm.)
