Form LASER transformer loading and super current amplifier
Output power (20Hz - 20kHz)
compact disk->SP-OUT, both channel drive 100W+100W (6ohm)
80W+80W (8ohm)
Dynamic power 2ohm: 265W+265W
4ohm: 205W+205W
6ohm: 150W+150W
THD (20Hz - 20kHz) 0.0015% (at compact disk->SP Out, the time of 10W output 8ohm)
0.003% (at the time of Phono man month->Rec Out and 3V output)
0.015% (at the time of Phono MC->Rec Out and 3V output)
Cross modulation distortion (20Hz - 20kHz) 0.004% (at the time of compact disk->SP Out and an Output power)
Power Band Width 5Hz - 100kHz (IHF-3dB, THD 0.2%, 8ohm)
Dumping factor 150 (1kHz, 8ohm)
Frequency characteristic Phono->Rec Out(RIAA deflection): 20Hz-20kHz±0.2dB
compact disk->SP Out: 2Hz-100kHz+0 -0.3dB
Phono maximum permissible input
(1kHz/10 kHz, 0.005%) MM:150mV/710mV
MC:9mV/42mV
Input sensitivity/impedance Phono man month: 2.5mV / 47kohm
Phono MC: 160 microvolts/220 ohm
compact disk, Tape Play, Processor IN, other:150mV /, 30kohm
An Output-power voltage / impedance Tape Rec, Processor Out, other:150mV/560 ohm
SN ratio (IHF-A filter input short-circuit) Phono man month: 94dB (5mV input)
Phono MC: 75dB (0.5mV input)
compact disk, other:107dB
The tone control maximum variation Bass: ±10dB (20Hz)
Treble: ±8dB (20kHz)
Muting -20dB
Power source AC100V, 50Hz/60Hz
AC outlet Switched: Two lines, 100W
Unswitched: One line, a total of 100W
Power consumption
(Electrical Appliance and Material Control Law specification) 190W
Dimensions Width 455x height 170x depth of 430mm
Weight 17.0kg
Adjunct Remote control
