Physical

Unit Weight 11.5 lbs [5.4 kg]
Unit Dimensions 14” x 8.3” x 2.4” [ 36cm x 21cm x 6.1cm]
Shipping Weight 20 lbs [9.1 kg]
Shipping Dimensions 22.5”x 13” x 6” [57cm x 33cm x 15cm]
Power requirements

Input Power Model specific 100VAC, 120VAC, or 230VAC 50 or 60Hz
Power Consumption 15W

Digtial audio inputs
Coax, TOSLINK, USB, I2S
Sample Rates
Coax Input
PCM 44.1KHz – 192KHz
Optical Input
PCM 44.1KHz – 96KHz
I2S
PCM 44.1KHz – 192KHz
DSD single rate (2.8KHz) and double rate (5.6MHz) raw
USB
USB2.0 Asynchronous Audio
PCM 44.1KHz – 192KHz
DSD single rate (2.8KHz) and double rate (5.6MHz) DoP
Analog Audio Output

Connector RCA/XLR Unbalanced /Balanced (X2)
Output level, maximum Unbalanced 2.8VRMS
Balanced 5.6 VRMS
Output Impedance 100Ω/200Ω
Frequency Response 10Hz – 20KHz +0/- 0.3dB
THD 1KHz, 0dBFS < 0.01%
20-20KHz, 0dBFS < 0.2%
1KHz, -10dBFS < 0.01%
Noise <-80dBV
Format PCM, DSD
