Mains voltage: 90 – 250 V, 50 - 60 Hz
Dimensions: 280 x 220 x 65 mm (W x D x H)
Weight: 3.30 kg
Power consumption: 0.2 W standby, 4 W network standby, 30 W max.

Network player

Ethernet: 10/100 Mbit/s
WLAN: 802.11b, g, n. 2.4 GHz band. WEP, WPA, WPA2 safety support. External screw-in antenna
DHCP and static IP support
USB 2.0 host interface: fullspeed and highspeed mode. Charging of smartphones and tablets up to 2.1 A. Support of mass storage devices with FAT16/32 file system, e.g. USB sticks, USB harddisks, smartphones and tablets
Internet Radio: vTuner
Gapless playback with WAV, AIFF, FLAC, ALAC, MP3
Meta data support
Supported formats: MP3 max. 320 kbit/s VBR/CBR | WAV and AIFF max. 192 kHz / 24 bit | FLAC max. 192 kHz / 24 bit | ALAC max. 96 kHz / 24 bit | AAC | Ogg Vorbis | WMA (only Standard, no Pro and Lossless)

Digital/analog converter

Inputs: two optical and two coaxial digital inputs (75 ohms) for SPDIF signals (LPCM) up to 192 kHz and 24 bit
Outputs: one optical and one coaxial digital output (75 ohms) for SPDIF signals
THD & Noise: <0.0005% (@ 0dBFS)
Dynamic range: >125 dB
D/A converter resolution: 352.8/384 kHz, 32 bit
Converter architecture: Anagram Sonic Scrambling DAC in dual-differential mono mode
Master clock: ultra stable dual-frequency clock with balanced clock lines (LVDS), jitter performance 250 femtoseconds
Multi-stage, synchronous data re-sampling
Jitter reduction: >60 dB
Digital filter: minimum phase "apodizing" filter
Output voltage: 2.50 V @ 0dBFS

Analog preamp

Inputs: analog line level inputs (RCA) with 10 kOhms input impedance
Outputs: one balanced (XLR) and one unbalanced (RCA) line level output with 100 ohms output impedance and 2.50V max. level (unbalanced) or 5V (balanced) resp.
Headphone connection: ¼“ (6.35 mm) jack socket for headphones with 32 – 300 ohms impedance
Circuit design: fully balanced signal path with special audio FDAs, balanced, analog volume control
Volume level control range: 0 to 99 with the following characteristic: 0 to 20 in 2 dB steps / 21 to 70 in 1 dB steps / 71 to 99 in 0.5 dB steps
Balance control range: +/- 6 dB in 1 dB steps
Maximum gain: 14 dB (5-fold)
Fixed line output (FLO) equals unity gain (0 dB), output voltage 2.50 V @ 0dBFS
Frequency response: 0 – 200 kHz (-3 dB)
THD & noise: <0.0005% @ 2.50 V output
