Audio Characteristics
SPDIF coaxial input 1 x (> 0.2v p-p / 75Ω)
SPDIF optical input 1 x (Toslink)
USB input 1 x (class1.0 / class 2.0)
SPDIF sampling frequency range 32 kHz – 192 kHz
USB sampling frequency range 44.1 kHz – 192 kHz
Resolution 16 – 24 bits
Bandwidth (± 0,2dB) 5 Hz – 100 kHz
Linearity (-100dB) 0,1 dB
Signal to noise ratio A weighted (20Hz – 20kHz) > 110 dB
THD + noise (1 kHz) < 0.002%
Output level 2 V rms
Output impedance 600 Ω
Mains Power supply
Type of cord C7
Mains voltage range 85 – 265 Vac
Mains frequency range 47 – 63 Hz
Standby consumption (85-140 Vac) < 0,5 W
Standby consumption (185-265 Vac) < 2,5 W
Operating consumption (85-265 Vac) < 2,5 W
Dimensions
Unit (L x H x W mm) 140 x 140 x 35
Packaging (L x H x W mm) 206 x 201 x 67
