Disc Capacity 1
Playback Formats SA-CD(Stereo), CD, CD-R/RW(CD-DA)
HDAM HDAM-SA2
Current Feedback Analog Stage Yes
Power Transformer Very Large Capacity Toroidal w/ Copper Shielded Case
Zero-Impedance Plate Yes
Double Layerd Bottom Plates Yes
Audio DAC NPC SM5866AS Monaural DAC x2
Display On/Off Yes
Selectable Filters Yes
SA-CD/CD Text X / -


SACD
Format 1-Bit DSD
Sampling Frequency 2.8224MHz
Dynamic Range 114dB
Frequency response 2Hz - 50kHz (-3dB)
THD 0.00%
CD Audio
Format 16-Bit Linear PCM
Sampling Frequency 44.1kHz
Dynamic Range 100dB
Frequency response 2Hz - 20kHz
THD 0.00%

Front Panel 3pces Aluminum
Remote Control No Aluminum Top with Marantz Amp. Basic Control Function
Power Requirement AC 120V 60Hz
Power Consumption 26W
Dimensions W x H x D (Inchs) 18”-1/8" x 5-7/16" x 16-13/16"
Weight (lbs) 49.1
