Operating System
CD digital audio system (CD, CD-R, CD-RW)
Frequency Response
20Hz – 20kHz ± 0.2dB
Harmonic Distortion
< 0.001% @ 0dB, 1kHz (Typically 0.0005%)
< 0.006% @ -30dB, 1kHz
< 0.01% @ 0dB, 20kHz
Intermodulation Distortion
< 0.001% @ 0dB (Typically 0.0005%)
S/N Ratio (IHF-A Wtd.)
105 dB
Wow & Flutter
Quartz precision
Channel Separation
>100 dB @ 1kHz
>80 dB @ 20kHz
Output Voltage
1.9Vrms
Digital Outputs
75 Ohm Coaxial, RCA
110 Ohm Balanced AES/EBU, XLR
Optical, Toslink
D/A Conversion
PCM1730E Advance Segment, Audio-Stereo DAC
Resolution/Sampling
24 bits / 192 kHz
Oscillation
3rd Overtone Oscillation
Crystal
Super precision, custom made
Jitter
<150 psec
Idle Pattern
<-115 dB
Stop band Rejection
<-78 dB
Power Supply
x2 high performance low noise toroidal transformers
10 fully regulated power rails
Power Source
100V – 120V 50Hz / 60Hz
220V – 240V 50Hz / 60Hz
Power Consumption
< 15 W
Dimension
432 x 330 x 70 (W x D x H) mm
432 x 330 x 80 (including feet)
Weight
9Kg
