Input Receiver UltraAnalog AES20 AES/EBU ultra-low jitter Input Receiver
Digital Filter NPC 5803 (8-times oversampling)
D/A Converter UltraAnalog D20400A (1 Dual)
Low Pass Analog Filter Proprietary passive configuration
Frequency Response 5 Hz to 20 kHz ± 0.2 dB
Intrinsic Jitter < 40 ps (picoseconds)
Jitter Rejection From 1 kHz and above (6 dB/octave)
“A” weighted S/N Ratio 105 dB (Balanced)
Crosstalk > 105 dB @ 1 kHz
> 95 dB 20Hz to 20 kHz
THD + Noise < 0.02% @ 1kHz
< 0.30% 20Hz to 20kHz
( balanced/ single- ended)
Output Voltage Approx. 2.2 Volts (single-ended)
Approx. 4.4 Volts (balanced)
Output Stage Fully balanced (for AC and DC parameters), high speed tube buffer
Digital Inputs Coaxial (RCA), Optical (H-P ST-Type glass), Optical (Toslink)
Analog Outputs 1 pr. Single-ended RCA
1 pr. Balanced XLR
Tube Complement 2 - 6922 (E88CC)
Dimensions 19” Wide x 11” Deep x 4” High (48 cm x 28 cm x 10 cm)
Weight 19.8 lbs (9 kg) - unpacked
Warranty 5 years parts and labor 1 year on the tubes
