Configuration Single-ended / 2-channel
Class of operation - Amplifier A/AB
Single Ended Inputs (RCA) 4 pairs
Mini-jack Input (1/8") 1
Optional Balanced Inputs (XLR) 1 pair
Input Sensitivity 400mV - 3.0V RMS
Input Impedance 22,000 Ω
Tape Output (fixed level) 1 pair
Preamplifier Output (variable level) 1 pair
Output Device Types - Amplifier Bipolars - 4 per channel
Output Binding Posts shielded
Output Power @ 8 Ω 100 Watts per channel
Output Power @ 4 Ω 200 Watts per channel
Output Impedance 0.04 Ω
Damping Factor > 200 (static)
Gain 37dB
Dynamic Headroom 3dB
Signal-to-noise Ratio > 110dB @ full power
Maximum Output Voltage 30 Volts
Slew Rate 20V/µs
Maximum Current - Peak 22 amperes
Maximum Current - Continuous 12 amperes
Frequency Response 2Hz - 90kHz (+0/-3dB)
Crosstalk @ 1kHz < -88dB
IMD < 0.03%
THD (20Hz - 20kHz @ 1 watt) < 0.03%
THD (20Hz - 20kHz @ 100 watts) < 0.05%


12 Volt Trigger Output Operation

Direct Logic (0V = off, 12V=on) using a 3.5mm
mono microphone jack with an output impedance
of 1000 Ω and current requirement of 12mA
SimLink Port 1 input + 1 output each on 1/8" mini-jack
RS-232 Port 9-pin female DB connector
IR input 1/8" mini-jack


Available Faceplate Finishes Black and Silver
Remote Control CRM-2 Full-Function
Power Consumption @ idle 45 Watts
AC Power Requirements 120V / 60Hz 240V / 50Hz
Fuse Replacement - 120V 5A long fast blow
Fuse Replacement - 230V 3A long fast blow
Shipping weight 28 lbs / 13 kgs
Dimensions (W x H x D) 16.9 x 3.5 x 14.8 in. (43.0 x 8.9 x 37.5 cm.)


Optional Digital-to-Analog Converter:

Digital Input Types S/PDIF (RCA) x 2 USB x 1 TosLink x 1
Digital Input Impedance S/PDIF 75 Ω @ 0.5 Volts
DAC / Digital Filter BurrBrown PCM1793
Bit-depth range - S/PDIF, Toslink 16 - 24 bits
Bit-depth range - USB 16 bits
Sampling Frequency Rate range - S/PDIF, Toslink 32, 44.1, 48, 88.2, 96, 176.4 and 192kHz
Sampling Frequency Rate range - USB 32 - 48kHz
Frequency Response (audible) 20Hz - 20kHz +0/-0.2dB
Frequency Response (full range) 2Hz - 72kHz +0/-3dB
THD @ 1kHz, 0dBFS (A-weighted) < 0.001 %
IMD < 0.004 %
Dynamic Range > 116dB
Signal-to-noise ratio > 115dB @ full output
Slew Rate 50V/µs
Channel Separation > 115dB
Low Level Linearity ±1.0dB to below 120dBFS
Intrinsic Jitter < 25 picoseconds RMS


Optional Phono Section:

Input Impedance - Adjustable 100 Ω and 47K Ω
Input Capacitance - Adjustable 0pF and 100pF
Gain - Adjustable 40dB and 60dB
Input overload @ 40dB gain 58mV RMS
Input overload @ 60dB gain 3mV RMS
Signal-to-noise Ratio (full scale @ 40dB gain) 107dBr
Signal-to-noise Ratio (full scale @ 60dB gain) 85dBr
Frequency Response 20Hz - 20kHz (±0.5dB)
Crosstalk @ 1kHz -97dB
IMD < 0.009%
THD (20Hz - 20kHz) < 0.001%
